CA 1000 7T
Throughput: 700–800 kg/h
- Elevator
- 7-Caliber Sizer - 1000mm Working Width
- Automatic Mobile Cart
Processing Lines
Prunes Processing Lines
Prune Sizing Line
CA-E 1000
Throughput: 700–800 kg/h
- Elevator
- 9-Caliber Sizer - 1000mm Working Width
- Automatic Mobile Cart
CA 1200
Throughput: 1.200–1.400 kg/h
- Elevator
- 7-Caliber Sizer - 1200mm Working Width
- Automatic Mobile Cart - 1200mm
CD 1200
Throughput: 1.200–1.400 kg/h
- Hydraulic Bin Tipper
- Elevator
- Cleaning Screen
- Vacuum Aspirator
- 7-Caliber Sizer - 1200mm Working Width
- Automatic Mobile Cart - 1200mm
CD 1500
Throughput: 2.500–2.700 kg/h
- Hydraulic Bin Tipper
- Elevator
- Cleaning Screen
- Vacuum Aspirator
- 7-Caliber Sizer - 1500mm Working Width
- Automatic Mobile Cart - 1500mm
CE 1200
Throughput: 1.500–1.700 kg/h
- Hydraulic Bin Tipper
- Elevator
- Cleaning Screen
- Vacuum Aspirator
- 13-Caliber Sizer - 1200mm Working Width
- Automatic Mobile Cart - 1200mm
CE-E 1200
Throughput: 1.500–1.700 kg/h
- Hydraulic Bin Tipper
- Elevator
- Cleaning Screen
- Vacuum Aspirator
- 15-Caliber Sizer - 1200mm Working Width
- Automatic Mobile Cart
CE 1500
Throughput: 2.800–3.000 kg/h
- Hydraulic Bin Tipper
- Elevator
- Cleaning Screen
- Vacuum Aspirator
- 13-Caliber Sizer - 1500mm Working Width
- Automatic Mobile Cart - 1500mm
CE-E 1500
Throughput: 2.800–3.000 kg/h
- Hydraulic Bin Tipper
- Elevator
- Cleaning Screen
- Vacuum Aspirator
- 15-Caliber Sizer - 1500mm Working Width
- Automatic Mobile Cart
CE 1800
Throughput: 3.500–3.800 kg/h
- Hydraulic Bin Tipper
- Elevator
- Cleaning Screen
- Vacuum Aspirator
- 13-Caliber Sizer - 1800mm Working Width
- Automatic Mobile Cart
CE-E 1800
Throughput: 3.500–3.800 kg/h
- Hydraulic Bin Tipper
- Elevator
- Cleaning Screen
- Vacuum Aspirator
- 15-Caliber Sizer - 1800mm Working Width
- Automatic Mobile Cart
CF 1200
Throughput: 1.200–1.400 kg/h
- Hydraulic Bin Tipper
- Elevator
- Cleaning Screen
- Vacuum Aspirator
- Inspection Conveyor
- 13-Caliber Sizer - 1200mm Working Width
- Automatic Mobile Cart - 1200mm
CF 1500
Throughput: 2.500–2.700 kg/h
- Hydraulic Bin Tipper
- Elevator
- Cleaning Screen
- Vacuum Aspirator
- Inspection Conveyor
- 13-Caliber Sizer - 1500mm Working Width
- Automatic Mobile Cart - 1500mm
CF 1800
Throughput: 3.300–3.500 kg/h
- Hydraulic Bin Tipper
- Elevator
- Cleaning Screen
- Vacuum Aspirator
- Inspection Conveyor
- 13-Caliber Sizer - 1800mm Working Width
- Automatic Mobile Cart
Integral Prune Pitting Line
CD 4
Throughput: 1.100 kg/h
- Hydraulic Bin Tipper
- Elevator
- Rotary Washer
- Inspection Conveyor
- Single-Cascade Washer
- Continuous Hydrator-Tenderizer
- Tenderizer Extraction Conveyor
- Collection Conveyor
- Elevator to Distribution Conveyor
- Pitter Distribution Conveyor
- Pitter
- Working Platform for 4 Pitters
- Pit Extraction Conveyor
- Prune Extraction Conveyor
- Elevator to Cleaning Screen
- Cleaning Screen
- Elevator to Brightener
- Brightener
- Illuminated Inspection Conveyor
- Weighing Elevator
- Roller Conveyor
CD 6
Throughput: 1.600 kg/h
- Hydraulic Bin Tipper
- Elevator
- Rotary Washer
- Inspection Conveyor
- Single-Cascade Washer
- Continuous Hydrator-Tenderizer
- Tenderizer Extraction Conveyor
- Collection Conveyor
- Elevator to Distribution Conveyor
- Pitter Distribution Conveyor
- Pitter
- Working Platform for 6 Pitters
- Pit Extraction Conveyor
- Prune Extraction Conveyor
- Elevator to Brightener
- Brightener
- Cleaning Screen
- Illuminated Inspection Conveyor
- Weighing Elevator
- Roller Conveyor
- Metal Detector
CD 8
Throughput: 2.200 kg/h
- Hydraulic Bin Tipper
- Elevator
- Rotary Washer
- Inspection Conveyor
- Single-Cascade Washer
- Continuous Hydrator-Tenderizer
- Tenderizer Extraction Conveyor
- Collection Conveyor
- Elevator to Distribution Conveyor
- Pitter Distribution Conveyor
- Pitter
- Working Platform for 8 Pitters
- Pit Extraction Conveyor
- Prune Extraction Conveyor
- Cleaning Screen
- Elevator to Brightener
- Brightener
- Illuminated Inspection Conveyor
- Weighing Elevator
- Roller Conveyor
- Metal Detector
Want to take it to the next level?
FAQ
Questions about processing lines for prunes
Which sizing line fits if my prunes already arrive clean?
If you already have your own pre-cleaning, the CA lines (CA 1000 7T, CA-E 1000 and CA 1200) handle only the sizing stage with three modules. If you need cleaning on the same line, the CD 1200, the CD 1500 and the CE and CE-E families add a bin tipper, cleaning screen and vacuum aspirator. If you also want visual inspection before sizing, the CF family adds an inspection conveyor.
What capacities do Albion's prune lines offer?
Sizing lines range from 700–800 kg/h (CA 1000 7T and CA-E 1000) to 3,500–3,800 kg/h (CE 1800 and CE-E 1800). The integral pitting lines process 1,100 kg/h (CD 4), 1,600 kg/h (CD 6) and 2,200 kg/h (CD 8).
Do I need a sizing line or a pitting line?
It depends on the product you sell. For prunes graded by size, a sizing line delivers 7 to 15 sizes depending on the model. For pitted prunes, the integral CD 4, CD 6 or CD 8 line washes, conditions, pits, brightens and weighs the fruit. If you need both processes, each line is sized to its own volume.
Can I add a Visys optical sorter to my pitting line?
Yes. Visys (Turkey) is a brand Albion represents and distributes in Argentina; Albion does not manufacture it. On prunes it works after pitting and uses X-ray to identify residual pit fragments inside the flesh, a defect human inspection cannot reliably catch at industrial speed.
How do I request a quote?
From any line's page or from the Contact page. Tell us which process you need (sizing or pitting), your estimated annual volume, how many sizes your buyers ask for and whether the fruit arrives pre-cleaned. With that information, we'll propose the right configuration.
